Learn: Design Resilient Architectures - Part 2

Overview

Welcome! In this deep dive, we’ll explore the architecture patterns, AWS services, and resilient design principles tested in “Design Resilient Architectures - Part 2.” By the end, you’ll have a solid grasp of migrating applications into containers, load balancing and high availability, multi-tier architectures, queuing and messaging concepts, and strategies for global performance. We’ll break down each topic, discuss typical AWS solutions, and walk through generic examples so you can confidently tackle similar architecture scenarios.

---

Concept-by-Concept Deep Dive

1. Migrating Applications to Containers on AWS

What it is:
Migrating legacy or monolithic applications to containers improves portability, scalability, and operational efficiency. Containers package code, dependencies, and environment settings, making deployments consistent across environments. On AWS, services like Amazon ECS (Elastic Container Service) and EKS (Elastic Kubernetes Service) orchestrate and manage container workloads.

Key Components:

• Container Orchestration: ECS or EKS automates deployment, scaling, and management.
• Data Persistence: Stateless containers need external persistent storage (e.g., EFS for files, RDS for relational data).
• Networking: Proper VPC, security group, and load balancer configurations ensure connectivity and isolation.

Step-by-Step Migration Recipe:

1. Assess Application Components: Identify which parts can run in containers and which need persistent storage.
2. Choose Orchestration Platform: ECS is simpler for most AWS-centric workloads; EKS for Kubernetes expertise or hybrid use.
3. Configure Storage: Use Amazon EFS for shared file storage needs; RDS/Aurora for transactional data; avoid local container storage for persistent needs.
4. Define Task Definitions: Specify container images, CPU/memory, storage, and networking for ECS/EKS tasks.
5. Automate Deployment: Use CodePipeline, ECS Blue/Green deployments, or EKS rolling updates for zero-downtime releases.

Common Misconceptions:

• Myth: Containers can keep persistent data inside them.
  Fix: Always externalize stateful data to managed services or storage volumes.
• Myth: ECS alone provides high availability.
  Fix: Ensure services span multiple Availability Zones and use load balancers for traffic distribution.

---

2. Load Balancing and Distributed Traffic Management

What it is:
Load balancing distributes incoming requests across multiple compute resources to improve reliability, availability, and performance. AWS offers Elastic Load Balancer (ELB) variants: Application Load Balancer (ALB), Network Load Balancer (NLB), and Classic Load Balancer (CLB).

Subsections:

• Types of Load Balancers:

  • ALB: Layer 7 (HTTP/HTTPS), supports routing, host/path-based rules.
  • NLB: Layer 4 (TCP/UDP), ultra-low latency, static IP, for extreme performance.
  • CLB: Legacy, basic load balancing.

• Cross-Zone Load Balancing: Ensures even distribution across all registered targets in all enabled Availability Zones.

• Global Load Balancing: Route 53 DNS-based routing or AWS Global Accelerator for global applications.

Step-by-Step Load Balancing Design:

1. Select Load Balancer Type: Match protocol and routing needs.
2. Enable Cross-Zone Load Balancing: For even failover and distribution.
3. Integrate with Auto Scaling: Attach load balancer to Auto Scaling groups for dynamic capacity.
4. Health Checks: Configure regular health checks to remove unhealthy instances.

Common Misconceptions:

• Myth: Load balancers maintain session state.
  Fix: Use stateless applications or session stickiness/cookies if state must be tracked.
• Myth: All ELB types support all protocols.
  Fix: ALB is for HTTP/HTTPS; NLB for TCP/UDP.

---

3. Designing for High Availability and Disaster Recovery

What it is:
High availability (HA) ensures your application remains operational through failures; disaster recovery (DR) minimizes data loss and downtime after catastrophic events. AWS provides multiple services and architectural patterns to support these goals.

Subtopics:

• Multi-AZ Deployments: Distribute resources across several Availability Zones for fault tolerance.
• RPO and RTO:
  • RPO (Recovery Point Objective): Maximum acceptable data loss in time.
  • RTO (Recovery Time Objective): Maximum acceptable downtime.
• DR Patterns: Backup & Restore, Pilot Light, Warm Standby, Multi-Site Active/Active.

Step-by-Step HA/DR Planning:

1. Assess Business Requirements: Define acceptable RPO and RTO values.
2. Choose DR Pattern: Based on RPO/RTO, cost, and complexity.
3. Implement Multi-AZ or Multi-Region: For critical databases, enable Multi-AZ or cross-region replication.
4. Automate Failover: Use Route 53 health checks, RDS failover, or custom scripts.

Common Misconceptions:

• Myth: Multi-AZ means Multi-Region.
  Fix: Multi-AZ is within a region; Multi-Region requires explicit cross-region replication.
• Myth: Snapshots alone provide high availability.
  Fix: Snapshots are for backup, not real-time failover.

---

4. Messaging, Queuing, and Event-Driven Architectures
