Overview

Welcome! Today, we're diving into the key ideas behind Plane and Spherical Trigonometry—a fascinating blend of geometry and advanced trigonometric reasoning. By the end of this session, you’ll understand how to distinguish between plane and spherical triangles, apply fundamental trigonometric rules, and solve problems involving angles, sides, and areas on both flat and curved surfaces. We'll also cover essential equations, clarify common misconceptions, and walk through worked examples that solidify your understanding.

Concept-by-Concept Deep Dive

1. Spherical vs. Plane Triangles

What It Is

A plane triangle exists on a flat surface (like paper), while a spherical triangle lies on the surface of a sphere, formed by arcs of great circles. Recognizing the geometric context is crucial, as the rules governing them differ, especially regarding angle sums and side relationships.

Key Differences

Angle Sums: In a plane triangle, the angles always sum to 180°, but in a spherical triangle, the sum exceeds 180° (up to 540°).
Sides and Angles: In spherical triangles, sides are measured as angles (degrees or radians), not lengths.

Reasoning to Distinguish

Identify if the triangle's context is curved (sphere) or flat (plane).
For spherical triangles, check if side lengths are given in degrees/radians.

Common Misconceptions

Confusing linear distance with angular measurement on a sphere.
Assuming plane triangle rules apply to spherical triangles.

2. Measuring Angles and Sides in Spherical Trigonometry

What It Is

In spherical trigonometry, both sides and angles are measured as angles (degrees/radians), corresponding to the arcs of great circles.

Components

Vertex Angles: Where two arcs intersect.
Side Lengths: Angular distances between vertices, measured at the sphere’s center.

Calculation Steps

To find an angle, use the intersection of arcs.
To find a side, measure the central angle subtended by the arc.

Misconceptions

Measuring sides as linear distances instead of angles.
Forgetting that all measurements on the sphere are angular.

3. Fundamental Trigonometric Functions and Identities

What It Is

Trigonometric functions (sine, cosine, tangent, secant) connect angles and side ratios in triangles. They’re foundational in both plane and spherical trigonometry.

Key Identities

tan(θ) = sin(θ)/cos(θ)
sec(θ) = 1/cos(θ)
Sine and Cosine Values: Learn key values like sin(30°), cos(45°), etc.

Calculation Recipe

For any right triangle, identify the side ratios (opposite/hypotenuse for sine, etc.).
Use calculators or memory for standard angle values.

Common Mistakes

Mixing up definitions (e.g., using adjacent instead of opposite).
Not recalling special angle values.

4. Area and Angle Excess in Spherical Triangles

What It Is

The area of a spherical triangle depends on its "angle excess"—the amount by which the sum of its angles exceeds 180°.

Components

Angle Excess (E): E = (A + B + C) - 180°
Area Formula: Area = E × (π/180) × R², where R is the sphere’s radius.

Calculation Steps

Add up the triangle's three interior angles.
Subtract 180° to get the excess.
Multiply the excess (in radians) by the sphere's surface area per radian.

Misconceptions

Trying to use Heron’s or plane triangle area formulas.
Forgetting to convert degrees to radians when necessary.

5. Major Spherical and Plane Triangle Theorems

What It Is

There are specialized laws for triangles on spheres, including the Spherical Law of Cosines, Law of Sines, and Napier’s Rules for right-angled spherical triangles.

Key Theorems

Spherical Law of Cosines: Relates sides and angles in a spherical triangle.
Spherical Law of Sines: Relates ratios of sines of sides and their opposite angles.
Napier’s Rule: Specific to right-angled spherical triangles; involves relationships among five elements (two sides, two angles, and the right angle).

Calculation Steps

Choose the appropriate law based on what is known (sides vs. angles; right-angled or not).
Substitute known values and solve for the unknown.

Common Misconceptions

Using plane triangle laws for spherical problems.
Not using the correct form of the law for right-angled triangles.

6. Problem Solving with Right Triangles and Special Triangles

What It Is

Right triangles (one 90° angle) allow direct use of basic trigonometric ratios, while isosceles triangles (two equal sides or angles) have their own properties.

Steps for Right Triangles

Use sine, cosine, and tangent to relate angles and sides.
Solve for unknowns using appropriate ratios.

Steps for Isosceles Triangles

Equal sides imply equal angles opposite them.
For known angle between equal sides, use Law of Cosines.

Common Errors

Assigning the wrong sides to the ratios.
Forgetting properties of isosceles triangles.

Worked Examples (generic)

Area of a Spherical Triangle
- Suppose a spherical triangle has angles of 80°, 95°, and 70°, and the sphere’s radius is R.
- Add the angles: 80 + 95 + 70 = 245°
- Find the excess: 245° - 180° = 65°
- Convert the excess to radians: 65 × (π/180)
- Area = [Excess in radians] × R²
Sine of an Angle in a Right Triangle
- Right triangle with hypotenuse h and side opposite angle θ as a.
- sin(θ) = a / h
Using the Spherical Law of Cosines
- Given sides a, b, and the angle C between them in a spherical triangle.
- cos(c) = cos(a)cos(b) + sin(a)sin(b)cos(C)
- Substitute known values and solve for c.
Height from Angle of Elevation
- A point is d meters from a building, angle of elevation is α.
- tan(α) = height / d ⇒ height = d × tan(α)

Common Pitfalls and Fixes

Mixing Plane and Spherical Rules: Always check the context; spherical triangles use angular measures and specialized laws.
Forgetting Units: Double-check if the question requires degrees or radians, especially for area calculations.
Misusing Trig Ratios: Remember which sides correspond to which ratios in right triangles.
Incorrectly Summing Angles: For spherical triangles, sum of angles is always greater than 180°.
Law Selection Error: Use Spherical Law of Cosines and Sines for spheres, plane versions for flat triangles.

Summary

Spherical triangles differ fundamentally from plane triangles in angle sums and side measurements.
Both spherical and plane triangles require careful selection of the correct trigonometric laws.
Sides in spherical triangles are angular, not linear.
The area of a spherical triangle depends on its angle excess over 180°.
Mastery of trigonometric values and identities is essential for both plane and spherical problems.
Always verify context and units before applying formulas or solving problems.
